Core Features & Advantages
High-Precision Filling:
Utilizes Servo Motor-driven pumps or Piston Fillers controlled by a PLC system, ensuring exceptional volumetric consistency for every container, minimizing product giveaway.
Excellent Product Versatility:
Capable of handling a broad spectrum of products, from low-viscosity liquids (oil, vinegar) to high-viscosity pastes (peanut butter) and products with large particulates.
Specialized anti-drip, self-closing filling nozzles prevent stringing and dripping, keeping the container mouth clean and reducing waste.
Customization
The CP-C-18 can be tailored to specific production needs with the following options:
Filling System Type: Piston Filler (for high accuracy/viscosity), Pump Filler (for versatility), Time-Pressure (for non-foaming liquids).
Capping System: Integrated automatic cap sorters, screw cappers (chuck or rotary magnetic), press-on cappers, or plug inserters.
Lifting System: Automatic container lifting table that raises the container to the nozzle, minimizing splashing and foam generation for sensitive products.
Special Functions: Nitrogen Purging (for product preservation), vacuum filling, level detection, metal detection integration interface.
Material Upgrade: Contact parts can be upgraded to SUS 316L stainless steel for corrosive products.
Target Industries & Product Applications
Condiments & Sauces: Ketchup, Mustard, Soy Sauce, Oyster Sauce, Barbecue Sauce.
Dairy & Spreads: Yogurt, Cream Cheese, Jam, Butter, Mayonnaise.
Food Manufacturing: Ready-meal sauces, Cooking oils, Vinegars.
Personal Care & Cosmetics (Similar Viscosity): Lotions, Creams, Shampoos.
Main performance parameter:
1.Outline dimension(L*W*H):2000mm*1200mm*1900mm
2.Number of filling head:18
3.Bottle application: diameter:φ40mm-φ100mm
height：80mm-320mm
4.Diameter of bottle mouth:≥φ16mm
5.Suitable range:150ml-800ml
6.Production capacity:≤5000bottles/hour(tested by water)
7.Filling error:±1.5ml（take 500ml for test）
8.Voltage:220v;50hz
9.Power of host machine:2kw
10.Weight :about 1280kg
