FJ-180ZL Automatic stand-up pouch packaging machine
//www.tompacks.com/uploadfiles/128.1.164.27/webid1348/source/201909/156956524177.jpg
Product Detail

Major characteristics

1.This machine is widely suitable for foodstuff , pesticide , pharmaceutical ,domestic chemical and other lines . Aimed at the material of liquid , powder , granule ,viscous body ,and the products can choose different kinds of filling style .

2. Frequency control system :import motor and frequency control speed , operating stable and reliable . Low velocity torque can also good operate well in the heavy load change situation .

3.Servo feeding system :servo motor directly control the feeding materiacs . The property is stable and the adjustment is easy and fast .

4.Pouch system :the pouch ,sealing and filling system are independent . The two systems are moved by the machine linkage and the PLC.So , it can be used for different packing objects.

5.Product packaging system : apply the heat-seal packaging material (polyethylene film , MLCM)to making the bags automatically . Metering filling and sealing are all automatic . The finished bag is the stand- up bag .

6.Integrated control system : apply PLC to control which is in high integrated level and hare, strong control ability and reliable operating . Photoelectric sensor , coder ,proximity switch , etc are all adoptled advanced imported sensor . So , it reflects the electromechanical integration faultlessly .

7.Servo pulling bag system :adopt PLC Located moudle to realize the accurate positioning . The pulling speed is stable and hare big torque . So it can guarantee the little error and the beautiful shape.


Main performance parameter:

1.Size of machine (L*W*H): 6000mm*1100mm*2200mm (different filling divice different height )

2.Bag size making single bag : min :90mm(w)*110mm(H) max :180mm(W)*270mm(H)

3.Maximum outside diameter : Φ600mm Inside diameter : Φ80mm

4.Power of host machine :5KW

5.Power supply :AC 380v 50HZ

6.Pneumatic (air-operated )source :0.6MPa (clean and stable air source )

7.Speed : ≤ 45 bags /minute

8.Weight :2500kg
